Compact Telehandler
Genie 5519
Additional Compact Telehandler Information
Our Genie 5519 Compact Telehandler also somewhat of an aerial lift, is perfect for tasks both large and small. It’s size makes it easy to maneuver on jobsites and also transportation is made simple by way of hauling with a normal equipment trailer, emphasis on meeting the needs of most construction projects including masonry, agricultural and landscape applications.
A fork attachment is standard but additionally you may choose or include the truss boom attachment option for an additional cost also. This Compact Telehandler provides all-around utility to answer virtually all your work site needs.
Genie Telehandlers offer exactly what you need for productivity in limited-access areas or applications where high reach is needed, therefore can easily handle even the most demanding jobs.
Finally, in addition to the rough terrain capability which allows access to difficult to reach areas or jobsites, the Genie 5519 has a stout lifting capacity which even at maximum height is 4,400 lbs. making this Compact Telehandler a very welcome machine for many applications.
Specifications
- Model: Genie GTH 5519.
- Weight will vary depending on attachment used.
- Max lift height: 18 ft. 10 inches.
- Maximum forward reach: 11 ft. 3 inches.
- Reach at maximum height: 1 ft. 10 inches.
- Height, stowed: 6 ft. 6 inches.
- Length, stowed: (without forks) 12 ft. 3 inches.
- Width: 5 ft. 11 inches.
- Wheelbase: 7 ft. 6 inches.
Productivity
Lifting capacity 5,500 lbs.
At maximum height – 4,400 lbs. is lifting capacity.
Extended at maximum reach lifting capacity – 1,900 lbs.
Drive speed 15 mph.
Draw bar pull 10,250 lbs.
Turning radius, outside (4WS) 11 ft.
Power
Power source: Deutz TD 2.9 L04 Tier 4f diesel 74 hp.
Electrical system: 12 volt.
Hydraulic tank capacity 18.5 gal.
Fuel tank capacity 15.8 gal.
Weight: 10,360 lbs.
Need more lifting height or weight capacity? Check out our full size unit here: Genie GTH-636 Full Size Telehandler
